Detail of one of the thermal insulation nutplates welded onto the hat bands on the nozzle extension.
Picture 1 of 4.
The thrust chamber proper instead used studs percussion welded onto hatbands to support the thermal insulation.
| Time picture taken | Mon Sep 9 12:21:46 2013 |
| Location picture taken |
Building 4205 Marshall Space Flight Center Huntsville, AL |
