Overall walk-around of F-1 engine.

Picture 5 of 7.

The dolly contains a number of warnings:

Max Towing Speed 2½ MPH

Install screw hand tight & torque 20-40 in-lbs with engine in assembly position

WARNING: Do not release 9024731 truss assy from engine or handler chassis unless engine is supported above with G4050 sling

Someone has also hand-labelled the dolly with "S/N 4023".

Time picture taken Fri Oct 24 15:57:50 2008
Location picture taken Building 4205
