The sign accompanying the heat shield manufacturing model.

It reads

Apollo Heat Shield Manufacturing Model

The manufacturing process was virtually the same for the large "aft heat shield" on the blunt end of the spacecraft and the heat shield that protected the cone-shaped surfaces all the way to the top. This model shows the various production stages.

Gift of the Avco Corporation
